Czujnik temperatury TP-953

Opis produktu

Czujnik w obudowie naściennej, do pomiaru temperatury powietrza wewnątrz lub na zewnątrz pomieszczeń.

Sprawdź inne czujniki temperatury z naszej oferty!

Dane techniczne

Zakres pomiarowy	-30÷70°C
Element przetwarzający	opornik platynowy Pt100 ⁽¹⁾ – pojedynczy lub podwójny
Klasa elementu przetwarzającego	A
Maksymalny prąd czujnika	1 mA
Dopuszczalna wilgotność względna	0÷80%
Materiał obudowy	PPO
Wyposażenie dodatkowe	przetwornik temperatury: stałozakresowy T, programowalny TE

⁽¹⁾ Na życzenie Pt500, Pt1000, Ni100, Ni1000

Załączniki do produktu

TP-951_953 karta katalogowa

{"element-przetwarzajacy":{"type":"translate","separator":"-","multiple":"0","translations":{"opornik-platynowy-pt100":{"value":"-","input":"0"},"opornik-platynowy-pt500":{"value":"Pt500","input":"0"},"opornik-platynowy-pt1000":{"value":"Pt1000","input":"0"},"opornik-niklowy-ni100":{"value":"Ni100","input":"0"},"opornik-niklowy-ni1000":{"value":"Ni1000","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"element-pojedynczy-podwojny":{"type":"translate","separator":"-","multiple":"0","translations":{"pojedynczy":{"value":"1","input":"0"},"podwojny":{"value":"2","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"przetwornik-temperatury-pt100":{"type":"translate","separator":"-","multiple":"0","translations":{"nie":{"value":"-","input":"0"},"analogowy-tch":{"value":"T","input":"0"},"programowalny-teh":{"value":"TE","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"-1","when":[{"field":"element-przetwarzajacy","is_equal":"-"},{"field":"element-pojedynczy-podwojny","is_equal":"1"}]}},"przetwornik-temperatury-ni100":{"type":"translate","separator":"-","multiple":"0","translations":{"nie":{"value":"-","input":"0"},"programowalny-teh":{"value":"T","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"-1","when":[{"field":"element-przetwarzajacy","is_equal":"Ni100"},{"field":"element-pojedynczy-podwojny","is_equal":"1"}]}},"montaz-termorezystora":{"type":"translate","separator":"","multiple":"0","translations":{"3-przewodowo":{"value":"-","input":"0"},"4-przewodowo":{"value":"(4p)","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"dol-zakresu-przetwarzania-przetwornika":{"type":"translate","separator":";","multiple":"0","translations":{"30c":{"value":"-30","input":"0"},"20c":{"value":"20","input":"0"},"10c":{"value":"10","input":"0"},"0c":{"value":"0","input":"0"},"wpisz-temperature-c":{"value":"","input":"1"}},"validation":{"required":"1","type":"number","range":[{"from":"-30","to":"40","field":"","value":""}]},"hint":"","display":{"always":"-2","when":[{"field":"przetwornik-temperatury-pt100","is_equal":"T,TE"},{"field":"przetwornik-temperatury-ni100","is_equal":"TE"}]}},"gora-zakresu-przetwarzania-przetwornika":{"type":"translate","separator":"","multiple":"0","translations":{"70c":{"value":"70","input":"0"},"60c":{"value":"60","input":"0"},"50c":{"value":"50","input":"0"},"40c":{"value":"40","input":"0"},"30c":{"value":"30","input":"0"},"wpisz-temperature-c":{"value":"","input":"1"}},"validation":{"required":"1","type":"number","range":[{"from":"0","to":"100","field":"","value":""}]},"hint":"","display":{"always":"-2","when":[{"field":"przetwornik-temperatury-pt100","is_equal":"T,TE"},{"field":"przetwornik-temperatury-ni100","is_equal":"TE"}]}},"wyjscie-przetwornika":{"type":"translate","separator":"\/","multiple":"0","translations":{"4-20ma":{"value":"4-20mA","input":"0"},"0-10v":{"value":"0-10V","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"-2","when":[{"field":"przetwornik-temperatury-pt100","is_equal":"T,TE"},{"field":"przetwornik-temperatury-ni100","is_equal":"TE"}]}}}

NAJPOPULARNIEJSZE WARIANTY

TP-953-1

109,00 zł
Stan: na zamówienie (wykonanie 2-7 dni)

TP-953-T (-30+70°C/4-20mA)

314,00 zł
Stan: na zamówienie (wykonanie 2-7 dni)

Ceny netto

Zapytaj o produkt

(+48) 22 720 31 80

Nasz ekspert pomoże Ci dopasować produkt do Twoich potrzeb

Możliwe wykonania

Czas realizacji zamówień wynosi 2-7 dni roboczych

element przetwarzający

element pojedynczy / podwójny

montaż termorezystora

Kod zamówieniowy:

Uwagi:

Dodaj do zapytania ofertowego
