Czujnik temperatury TP-386

Opis produktu

Czujnik do pomiaru temperatury powierzchni rurociągów lub elementów walcowych. Mocowany za pomocą opaski zaciskowej.

Sprawdź również inne czujniki temperatury z oferty Czaki!

Dane techniczne

Zakres pomiarowy	-40÷400°C
Element przetwarzający	opornik platynowy Pt100 ⁽¹⁾ termoelement Cu-CuNi (T) termoelement Fe-CuNi (J) termoelement NiCr-NiAl (K)
Rodzaj spoiny pomiarowej termoelementu	izolowana ⁽²⁾
Klasa elementu przetwarzającego	2 (B) ⁽⁴⁾
Średnica rury	50÷200 mm
Materiał osłony	stal 1H18N9T
Materiał radiatora	mosiądz
Długość przewodu L_k	0.5, 1.5, 2.5 m ⁽⁴⁾
Izolacja przewodu	włókno szklane i ekran stalowy ⁽³⁾
Wyposażenie dodatkowe (dla wykonania X)	opaska zaciskowa OZ

⁽¹⁾ na życzenie Pt500, Pt1000, Ni100, Ni1000
⁽²⁾ na życzenie wykonanie podwójne
⁽³⁾ na życzenie inne izolacje przewodu PVC, silikon, teflon, pancerz
⁽⁴⁾ inne parametry na życzenie

Załączniki do produktu

TP-386_karta_katalogowa

{"element-przetwarzajacy":{"type":"translate","separator":"","multiple":"0","translations":{"opornik-platynowy-pt100":{"value":"Pt100","input":"0"},"termoelement-k-nicr-nial":{"value":"K","input":"0"},"termoelement-j-fe-cuni":{"value":"J","input":"0"},"termoelement-t-cu-cuni":{"value":"T","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"wykonanie":{"type":"translate","separator":"-","multiple":"0","translations":{"wykonanie-x":{"value":"X","input":"0"},"wykonanie-z":{"value":"Z","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"srednica-rurociagu-mm":{"type":"translate","separator":"-","multiple":"0","translations":{"50":{"value":"","input":"0"},"80":{"value":"","input":"0"},"100":{"value":"","input":"0"},"120":{"value":"","input":"0"},"150":{"value":"","input":"0"},"200":{"value":"","input":"0"},"inna-z-zakresu-50-200":{"value":"","input":"1"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"-1","when":[{"field":"wykonanie","is_equal":"X"}]}},"dlugosc-przewodu-lk-m":{"type":"translate","separator":"-","multiple":"0","translations":{"05":{"value":"","input":"0"},"15":{"value":"","input":"0"},"25":{"value":"","input":"0"},"inna":{"value":"","input":"1"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"wyposazenie-dodatkowe":{"type":"translate","separator":"-","multiple":"0","translations":{"brak":{"value":"-","input":"0"},"opaska-zaciskowa":{"value":"OZ","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"-1","when":[{"field":"wykonanie","is_equal":"X"}]}},"opcje-przewod":{"type":"translate","separator":" ","multiple":"0","translations":{"wykonanie-standardowe-wlokno-szklane-i-ekran-stalowy-tmax-400c":{"value":"-","input":"0"},"pvc-tmax-80c":{"value":"(PVC)","input":"0"},"silikon-tmax-180c":{"value":"(silikon)","input":"0"},"teflon-tmax-260c":{"value":"(teflon)","input":"0"},"pancerz":{"value":"(pancerz)","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"wymagania-dodatkowe":{"type":"translate","separator":"","multiple":"0","translations":{"brak":{"value":"-","input":"0"},"dodaj":{"value":"(","input":"1"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"inne wymiary radiatora, inna klasa, wykonanie 3- 4-żyłowo, wykonanie podwójne","display":{"always":"1","when":[{"field":"","is_equal":""}]}}}

NAJPOPULARNIEJSZE WARIANTY

TP-386Pt100-Z-2,5

155,00 zł
Stan: 5

Ceny netto

Zapytaj o produkt

(+48) 22 720 31 80

Nasz ekspert pomoże Ci dopasować produkt do Twoich potrzeb

Możliwe wykonania

Czas realizacji zamówień wynosi 2-7 dni roboczych

element przetwarzający

wykonanie

długość przewodu (Lk) [m]

opcje - przewód

wymagania dodatkowe ?

Kod zamówieniowy:

Uwagi:

Dodaj do zapytania ofertowego
