Czujnik temperatury TP-377

Opis produktu

Czujnik do pomiaru temperatury części maszyn z ruchomym mocowaniem.

Dane techniczne

Zakres pomiarowy	-40÷400°C
Element przetwarzający	opornik platynowy Pt100 ⁽¹⁾ termoelement Cu-CuNi (T) termoelement Fe-CuNi (J) termoelement NiCr-NiAl (K)
Rodzaj spoiny pomiarowej termoelementu	izolowana ⁽²⁾
Klasa elementu przetwarzającego	2 (B) ⁽²⁾
Długość czujnika L	20÷1000 mm ⁽²⁾
Średnica osłony Ø	4, 5, 6 mm ⁽²⁾
Materiał osłony	stal 1H18N9T
Izolacja przewodu	włókno szklane i ekran stalowy ⁽³⁾
Długość przewodu L_K	0,5÷5 m ⁽²⁾
Przyłącze procesowe	ruchomy uchwyt z gwintem zewnętrznym
Wielkość gwintu M	M20x1,5, G1/2″ ⁽²⁾

⁽¹⁾ na życzenie Pt500, Pt1000, Ni100, Ni1000
⁽²⁾ inne parametry i wymiary na życzenie
⁽³⁾ na życzenie inne izolacje przewodu PCV, silikon, teflon, pancerz
