Czujnik temperatury TP-291 (termoelement płaszczowy)

Opis produktu

Czujnik temperatury z giętkiego termoelementu płaszczowego, z płaską końcówką do pomiarów temperatury powierzchni.

Dane techniczne

Rodzaj termoelementu	Zakres temperaturowy
Fe-CuNi (J)	-40°C÷700°C
NiCr-NiAl (K)	-40°C÷700°C

Klasa elementu przetwarzającego	2
Spoina pomiarowa termoelementu	a: uziemiona b: izolowana
Średnica termoelementu	1,5 mm
Długość termopary	100, 200, 300, 400, 600, 800 mm ⁽¹⁾
Długość przewodu kompensacyjnego	1,5m ⁽¹⁾
Materiał końcówki pomiarowej	Cu
Materiał osłony termoelementu	Inconel
Temperatura pracy przewodu i tulei pośredniczącej	-20÷80°C
Wyposażenie dodatkowe	wtyk MT

^{(1) Inne parametry na życzenie}

Załączniki do produktu

TP-291 karta katalogowa

{"rodzaj-termoelementu":{"type":"translate","separator":"","multiple":"0","translations":{"k-nicr-nial":{"value":"K","input":"0"},"j-fe-cuni":{"value":"J","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"rodzaj-spoiny":{"type":"translate","separator":"-","multiple":"0","translations":{"b-izolowana":{"value":"b","input":"0"},"a-uziemiona":{"value":"a","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"dlugosc-termopary-l-mm":{"type":"translate","separator":"-","multiple":"0","translations":{"100":{"value":"","input":"0"},"200":{"value":"","input":"0"},"300":{"value":"","input":"0"},"400":{"value":"","input":"0"},"600":{"value":"","input":"0"},"800":{"value":"","input":"0"},"inna":{"value":"","input":"1"}},"validation":{"required":"1","type":"number","range":[{"from":"50","to":"20000","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"wyposazenie-dodatkowe":{"type":"translate","separator":"-","multiple":"0","translations":{"brak":{"value":"-","input":"0"},"wtyk-mt":{"value":"MT","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"opcje-dl-przewodu-lk-m":{"type":"translate","separator":" (","multiple":"0","translations":{"15":{"value":"-","input":"0"},"1":{"value":"1,0)","input":"0"},"25":{"value":"2,5)","input":"0"},"inna":{"value":"","input":"1"}},"validation":{"required":"1","type":"number","range":[{"from":"1","to":"50000","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"opcje-przewod":{"type":"translate","separator":" ","multiple":"0","translations":{"standard-pvc":{"value":"-","input":"0"},"silikon":{"value":"(silikon)","input":"0"},"teflon":{"value":"(teflon)","input":"0"},"wlokno-szklane-ekran-stalowy":{"value":"(szkło+ekran)","input":"0"},"pancerz":{"value":"(pancerz)","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}}}

Zapytaj o produkt

(+48) 22 720 31 80

Nasz ekspert pomoże Ci dopasować produkt do Twoich potrzeb

Możliwe wykonania

Czas realizacji zamówień wynosi 2-7 dni roboczych

rodzaj termoelementu

rodzaj spoiny

długość termopary (L) [mm]

wyposażenie dodatkowe

opcje - dł. przewodu (Lk) [m]

opcje - przewód

Kod zamówieniowy:

Uwagi:
