Temperature sensor TP-958

Product description

Sensor for measuring the surface temperature of blocks and construction elements made of magnetic materials.

Technical data

Temperature range	0÷70°C
Measuring elements	platinum resistor Pt100
Sensor class	B
Maximum resistor current	1 mA
Magnetic material	Alnico
Case material	PC
Ingress protection	IP54
Optional accesories	temperature transmitter

Product attachments

TP-958 data sheet

{"element-przetwarzajacy":{"type":"translate","separator":"","multiple":"0","translations":{"resistor-pt100":{"value":"-","input":"0"},"resistor-pt500":{"value":"Pt500","input":"0"},"resistor-pt1000":{"value":"Pt1000","input":"0"},"resistor-ni100":{"value":"Ni100","input":"0"},"resistor-ni1000":{"value":"Ni1000","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"1","when":[{"field":"","is_equal":""}]}},"przetwornik-temperatury-pt100":{"type":"translate","separator":"","multiple":"0","translations":{"none":{"value":"-","input":"0"},"with-fixed-range-tch":{"value":"T","input":"0"},"with-programmable-range-teh":{"value":"TE","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"-1","when":[{"field":"element-przetwarzajacy","is_equal":"-"}]}},"przetwornik-temperatury-ni100":{"type":"translate","separator":"-","multiple":"0","translations":{"none":{"value":"-","input":"0"},"with-programmable-range-teh":{"value":"TE","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"-1","when":[{"field":"element-przetwarzajacy","is_equal":"Ni100"}]}},"dol-zakresu-przetwarzania-przetwornika":{"type":"translate","separator":";","multiple":"0","translations":{"0c":{"value":"","input":"0"},"10c":{"value":"","input":"0"},"20c":{"value":"","input":"0"},"other":{"value":"","input":"1"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"-2","when":[{"field":"przetwornik-temperatury-pt100","is_equal":"T,TE"},{"field":"przetwornik-temperatury-ni100","is_equal":"TE"}]}},"gora-zakresu-przetwarzania-przetwornika":{"type":"translate","separator":"","multiple":"0","translations":{"70c":{"value":"","input":"0"},"60c":{"value":"","input":"0"},"50c":{"value":"","input":"0"},"40c":{"value":"","input":"0"},"30c":{"value":"","input":"0"},"other":{"value":"","input":"1"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"-2","when":[{"field":"przetwornik-temperatury-pt100","is_equal":"T,TE"},{"field":"przetwornik-temperatury-ni100","is_equal":"TE"}]}},"wyjscie-przetwornika":{"type":"translate","separator":"\/","multiple":"0","translations":{"4-20ma":{"value":"","input":"0"},"0-10v":{"value":"","input":"0"}},"validation":{"required":"0","type":"","range":[{"from":"","to":"","field":"","value":""}]},"hint":"","display":{"always":"-2","when":[{"field":"przetwornik-temperatury-pt100","is_equal":"T,TE"},{"field":"przetwornik-temperatury-ni100","is_equal":"TE"}]}}}

Ask about the product

(+48) 22 720 31 80

Our experts will help you to customize the product

Possible variants

Delivery time is 2-7 business days

element przetwarzający

resistor Pt100▾

resistor Pt100
resistor Pt500
resistor Pt1000
resistor Ni100
resistor Ni1000

temperature transmitter (Pt100)

none▾

none
with fixed range (TCH)
with programmable range (TEH)

Ordering code:
